| Felgen: |
J24SE double wall MATT Black,A/V |
| Reifen: |
K1185,rubber,60TPI,black,stab-proof,w/ reflective stripe |
| Naben: |
FORMULA |
| Speichen: |
Stainless steel 304 C17,14G,286mm,black,w/ 16mm milling-slot copper cap(light yellow)&284mm,black,w/ 16mm milling-slot copper cap(light yellow) |
| Bleche: |
YSHJD58F-700C-003/YSHJD58R-700C-020,AGO AIR,D58,aluminum reinforced,matt black,outer wide 58MM,height 19mm,front & rear U-type black stainless steel adjustable mudguard stay |
| Sattel: |
Saddle A037D,w/satey line,W/o clamp',270*200mm, |
| Sattelstütze: |
ESP-D609,aluminum,matt black,ø30.4*350mm*3.2T,Offset 21mm |
| Lenker: |
MHB-A6009BT,aluminum,matt black,riser handlebar,W:700MM,fit with stem φ31.8MM,H=40MM,12°,grip distance≥185MM |
| Vorbau: |
EAS-JD6609-8/0,aluminum,matt black,intergrated,E:100mm,fit for handlebar φ31.8mm,fit for fork tube φ28.6*35mm,angle adjustable:0° to +90°,cover fit for front light hanger inner diameter 10mm,φ6 hole,w/o LOGO,original angle 0° |
| Griffe: |
HL-G170,black,130MM,bi-pass,w/ black plug,aluminum anode black locking ring,black stainless steel screw |
| Steuersatz: |
H886G inside cable threading head set,hidden toothless head set,aluminum,matt black,Φ28.8*Φ56*Φ39.8 |
| Beleuchtung: |
AGO AIR)DH011,front light,LED,12-48V,w/ 2-core cable length w/ end 150mm |
| Rückleuchte: |
rear light，model COBC,6-36VDC,IPX5 |
| Pedale: |
23ZP,copper bearing,aluminum body+TPR edge,black,9/16",BS/CPSC/DIN standard reflector |
| Kurbelsatz: |
PROWHEEL alloy 170mm, powder sand black w/o fixing bolt |
| Zahnkränze: |
PROWHEEL Alloy 40T Chainwheel /SHIAMNO 9-SPEED CASSETTE 11-41T |
| Kette: |
SHIMAO 9-Speed+MID Motor+Chain |
| Rahmengrössen: |
43cm |
