| Reifen: |
CST, C-1880,rubber,black,EPS stab-proof,anti-abration, reflective stripe28*1.75*2.00,CST tire,60TPI |
| Speichen: |
Front: stainless steel 304H,13G,260mm,black& stainless steel 304H,14G,290mm. Rear: stainless steel 304H,14G,286mm,black& stainless steel 304H,13G,261mm,black |
| Bleche: |
NB70K-600PLUS-002,front / rear mudguard D58,aluminum,matt black,width 58MM,height 19mm,black stainless steel stay |
| Sattel: |
Aifeit,62450-04#S04,black leather,w/o pattern,black protective cover,BED bridge+scale,w/o LOGO,271*148MM |
| Sattelstütze: |
RSP-AD001,aluminum,matt black,ø30.4*350mm,laser carving safety line and scale,w/ black clip,black screws,w/o LOGO,ISO-M standard |
| Lenker: |
MHB-6045BT,aluminum,matt black,straight handlebar,W:620MM*1.8T,ø31.8MM,6°,grip width≥185MM,w/o LOGO,ISO-M standard |
| Vorbau: |
CAS-JD6601N-8/0,aluminum,SABK matt black,intergrated,E:110mm,φ31.8mm for hadndlebar,φ28.6*35mm for fork,angle adjustable:-20° to +90°,w/o LOGO,original angle 110°, all accessories are black |
| Griffe: |
HL-G318,rubber,black,130MM,single pass,w/ aluminum anode black locking ring |
| Steuersatz: |
KL-B570HT,hidden toothless bearing head set,for head tube inside cable,cable hole 7.8*15MM,material:A6061,black,ø28.6*ø51.8*ø51.8*ø39.8,H:11.5MM,w/ star/black cylinder hex screw M6*40MM,w/o aluminum cover |
| Beleuchtung: |
DHY05,front light,LED,6V,w/ 2 core cable w/ end 125MM(Bafang M2.6 female end),CE/ROHS,w/ 2PCS black countersunk cross screw M3*10,black rubber plug 2PCS |
| Rückleuchte: |
Mudguard rear light,6~48V,black plastic shell,red light cover,w/ reflector,cable w/ end 1270mm(G2.6 male end,blue for positive and black for negative),w/ black screw |
| Pedale: |
FP-877ZP,engineering plastic composite material,black,9/16",w/ bead,BS/CPSC/DIN standard reflector,ISO-M,stick 'L' & 'R' label as dwg: PD21-0001 |
| Ständer: |
YX-KS11D,aluminum,matt black,285-355MM adjustable,lock hole distance 40MM,w/ 2PCS black screws M6*20MM(w/ teflon paste,w/ outer diameter φ10 spacer),plastic black kickstand |
| Kurbelsatz: |
NWA48A-S1-3,3/32*48T,FD05-48T (CNC) anode matt black(wide narrow teeth),S1-3 aluminum four-arm anode matt black,cover anode matt black, BCD104,CL52.5,fit with Bafang (SR,PA232.32.ST,148,001) sensor |
| Rahmengrössen: |
50 cm, 54 cm, 58 cm |
