| Reifen: |
CST, C1635,rubber,60TPI,black,28"*2.0"(700*48C),3mm orange stab-proof,w/ reflective stripe |
| Speichen: |
Front: Stainless steel 304H,14G,290mm,black& stainless steel 304H,14G,286mm,black. Rear: stainless steel 304H,13G,261mm,black& stainless steel 304H,13G,260mm,black |
| Bleche: |
Mudguard,D58,aluminum,2.0T matt black,wide 58mm,height 19mm,w/ black stainless steel stays(L=??MM),w/ black adjuster and screw accessory,w/ CP-001 connecting clip,front fixed hanger,rear fixed hole, cable hole on left of rear mudguard |
| Sattel: |
SR, A037HR0028014,black 8014#/vacuum foaming/ bridge BED print 065# scale mark,no clip/no edge |
| Sattelstütze: |
RSP-AD001,aluminum,matt black,ø30.4*350mm,laser carving safety line and scale,w/ black clip,black screws, ISO-M standard |
| Lenker: |
CHB-A6353 and add 2 cable threading holes as CBH-C-G800-002C,aluminum,matt black,riser handlebar,W:635MM*2.2T,fit with stem φ31.8MM,H:41MM,37°,grip distance≥185MM |
| Griffe: |
G220,black PU,130MM,bi-pass,w/ black HL-05 plug (ø19.9),w/ aluminum anode black locking ring |
| Steuersatz: |
FP-H869T,hidden toothless head set,aluminum,matt black,Φ28.6*Φ41.8*52*Φ39.8,H:11.2mm,w/o locker |
| Beleuchtung: |
DH002 front light(w/ reflector),black,LED,6-48V,bracket DZ01,cable w/ end 50MM(2 core male end M2.6),cable dwg: EB,S1T0,032,CE/ECE/ROHS standard |
| Pedale: |
FP-893ZU,plastic,black,sand paper on surface,9/16",hexahedral shaft,sleeve plain bearing,w/ reflector |
| Ständer: |
YX-KS11D,aluminum,matt black,285-355MM adjustable,lock hole distance 40MM,w/ 2PCS black screws M6*20MM(w/ teflon paste,w/ outer diameter φ10 spacer),plastic black kickstand |
| Gepäckträger: |
Rear carrier,aluminum,matt black |
| Kurbelsatz: |
NWA48A-S1-3,3/32*48T,FD05-48T (CNC) anode matt black(wide narrow teeth),S1-3 aluminum four-arm anode matt black,cover anode matt black, BCD104,CL52.5,fit with Bafang (SR,PA232.32.ST,148,001) sensor |
| Rahmengrössen: |
48 cm |
